SOLAR PANEL- 120W Portable Folding Solar Mat
Excludes freight and installation
Description
The new KT Solar 120W, 12V Portable Folding Solar Mat is designed for ultimate solar performance. Featuring 6 powerful monocrystalline cells in a 20W configuration.
With its unique and compact size, the 120W Portable Folding Solar Mat can either lay flat or hang via corner eyelets for maximum solar positioning. Conveniently, the 120W Mat’s design allows it to fold down into a convenient carry bag with room for all leads and accessories.
Your KT Solar 120W Portable Folding Solar Mat also comes equipped with a 10Amp, 12V PWM Solar Controller, which displays battery voltage, battery capacity percentage, ambient temperature
& load mode.
Key Features:
POWERFUL FOR ULTIMATE SOLAR POWER PERFORMANCE
6 x Powerful Monocrystalline Cells / Configured 20W Cells
UNIQUE, COMPACT SIZE FOR STORAGE CONVENIENCE
Folds down to a compact 395mm x 360mm 80mm and folds out to 2285mm x 360mm x 5mm
FLEXIBLE CHARGING CAPABILITIES
Compatible with WET, AGM & CALCIUM batteries
IDEAL FOR CAMPING, 4WD & OUTDOOR APPLICATIONS
Perfect for charging 12V batteries that power camping fridges, lighting, air-compressors & other 12V devices
Specifications:
Power Tolerance +3%
Maximum Power (Pmax) 120Wp
Maximum Power Voltage (Vmp) 19.6V
Maximum Power Current (Imp) 6.12A
Rated Voltage 12V
Open Circuit Voltage (Voc) 23.2V
Short Circuit Current (Isc) 6.67A
Operating Temperature -40°C to +85°C
Product Application Class A
Max System Voltage 1000V DC
Dimensions & Weight:
Dimensions unfolded (mm): 2285 x 360 x 5
Dimensions folded (mm): 395 x 360 x 80
Weight: 5.0Kg
