SOLAR PANEL - 120 Watt, 12V Single Cell Mono-crystalline Solar Panel
Excludes freight and installation
Description
Designed for installation on 4WD, caravans, campers, motorhomes, RV’s, large boats & yachts.
Ideal for home & rural applications including 12V home surveillance systems, irrigation systems, electric fences, electric gates & off-grid shed power.
Requires regulations from solar charge controller.
Suited to KT Solar Controller Model No. KT70756 – 10 Amp PWM Solar Charge Controller.
Features 900mm PV cables terminated to male & female TUV certified solar connectors.
Features:
Ideal for installation on 4WD’s, caravans, campers, motorhomes, commercial vehicles, boats & yachts
Ideal for home & rural applications including 12V home surveillance systems, irrigation systems, electric fences/gates & off-grid shed power
Requires regulation by solar charge controller
Direct connection to batteries with 90mm PV cables with positive (+) and negative (-) TUV certified connectors
Specifications:
Power Tolerance +3%
Maximum Power (Pmax) 120Wp
Maximum Power Voltage (Vmp) 19.0V
Maximum Power Current (Imp) 6.32A
Rated Voltage 12V
Open Circuit Voltage (Voc) 22.5V
Short Circuit Current (Isc) 6.97A
Operating Temperature -40°C to +85°C
Product Application Class A
Max System Voltage 1000V DC
Dimensions & Weight:
Dimensions (Height): 945mm
Dimensions (Length): 670mm
Dimensions (Depth): 35mm
Panel Weight: 6.90Kg
